Directory data

Pipe types, pump types and customer types are all examples of directory data.

Summary: object data - model data

	Object-specific data Production plant ID Name Comments         Accumulator ID Name Comments       Heat exchanger ID Name Comments       Pump ID Name Comments               Valve ID Name Comments           Pipe ID Name Comments Length, supply/return pipe [m Coordinates for direction changes Ambient temperature [°C   Node ID Name Comments Type x coordinate y coordinate z coordinate		Model-specific data Temperature [°C Power [kW Flow [kg/s Static pressure/Location [kPa Pump type Max./min. power Temperature programmes   Volume [m³ Max./min.temperature [°C Initial temperature [°C Nominal power [kW Heat loss [kW/°C Ambient temperature [°C   Basic power [kW Temperature dependency [kW/°C Location, supply/return pipe Location, node 1/2       Fixt lift, supply/return pipe [kPa Revs, supply/return pipe [revs/s Location, node 1/2 Pump type Reference value, node Reference value, type Reference value [kPa         Fixt pressure reduction, supply/return pipe [kPa Location, node 1/2 Opening degree [0-90° Valve type Reference value, node Reference value, type Reference value [kPa     Pipe type, supply/return pipe Closing mode Network level Resistance factor, supply/return pipe Dimensioning criteria     Output [kW / Flow [kg/s Cooling/return temperature [°C Shunt temperature [°C Bypass [mm or Kv value
